Product image for ACME TB2000F012 ICT 2KVA 240,347,38
Email

ACME TB2000F012 ICT 2KVA 240,347,38

Manufacturer: Acme Electric | Catalog # TB2000F012 | Cooper Electric Part # 1338526
$400.88/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Safety Data Sheet Product Brochure
Acme.s TB Series Industrial Control Transformers are especially designed to accommodate the momentary current inrush caused when electromagnetic components are energized... without sacrificing secondary voltage stability beyond practical limits. The transformer.s windings and internal terminations are sealed within an epoxy encapsulant encased in a durable thermoplastic end cap, protecting them from potentially damaging moisture, dirt and other ambient contaminants. Acme.s TB Series transformers are dry-type, step-down transformers with the secondary control circuit isolated from the primary line circuit to assure maximum safety.

Technical Information

Applications
Open Core & Coil
Frequency
50 Hz
Max Output Current
16.67,8.33
Number of Phases
1 Phase
Primary Voltage
240 V
Secondary Voltage
120 V
Standard
CSA 22.2 No 66.1,CSA 22.2 No 66.2,UL 5085-1,UL 5085-2
Temperature Rating
115 C
Type
2000VA
Wattage
2000 Watt

Manufacturer Information

Brand
Acme Electric Company
Sub Brand
Industrial Control

General Product Info

12-Digit UPC
047503005248
Construction
Encapsulated
GTiN
00047503005248
Product UPC
04750300524
Weight
61.1 lb

Dimensions

Height
8.88 Inch
Length
5.79 Inch
Width
6.75 in

Certifications and Compliance

Country of Origin
USA
Features
  • Secondary fuse clips factory installed, where applicable
  • Twenty year limited warranty
  • UL Listed and CSA Certified or cUL
  • Epoxy encapsulated design protects core & coil assembly from potentially damaging contaminants
