Product image for Square D CA2KN31G7 120 VAC 10 Amp 4.5 VA 4-Pole 3NO 1NC IEC Control Relay
Image thumbnail 0
Image thumbnail 2
Image thumbnail 3
Email

Square D CA2KN31G7 120 VAC 10 Amp 4.5 VA 4-Pole 3NO 1NC IEC Control Relay

Manufacturer: Square-D / Schneider | Catalog # CA2KN31G7 | Cooper Electric Part # 131178
$63.58/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
TeSys K IEC industrial control relays are used in industrial control circuits. This Type K control relays has 3 normally open and 1 normally closed contacts. The contacts have AC-15 and DC13 contact ratings. Type K control relays can be mounted on 35mm DIN rail or can be mounted directed to a panel. The relay has a 120 VAC 50/60 Hz coil. Screw clamp terminals are used for load and auxiliary connections. An extensive line of accessories makes it easy to meet the requirements of most applications. The relay is 2.28 inches tall, 1.77 inches wide and 2.24 inches deep. It weighs 0.40 lbs. This control relay is UL Listed and CSA certified.

Technical Information

Amperage
10 Amp AT <= 50 ?C
Applications
Control circuit
Contact Configuration
3 NO + 1 NC
Contact Rating
<= 690 V <= 400 HZ
Enclosure
IP2X
Net Weight
0.18 kg
Operating Cycles
10000 cyc/h
Operating Temperature
-25-50 Adegrees C
Size
2.24 in
Standard
CSA C22.2 No 60947-4-1,EN/IEC 60947-4-1,GB/T 14048.4,JIS C8201-4-1,UL 60947-4-1
Storage Temperature
-50-80 degrees C
TC Connection
SCREW CLAMP TERMINALS 1 1.5-4 MMASOLID- SCREW CLAMP TERMINALS 2 1.5-4 MMASOLID- SCREW CLAMP TERMINALS 1 0.75-4 MMAFLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.75-4 MMAFLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 0.34-1.5 MMAFLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.34-1.5 MMAFLEXIBLE WITHOUT CABLE END
Type
Control relay
Voltage
690 Volt

Manufacturer Information

Brand
Schneider Electric
Sub Brand
CA2K;TeSys CAK

General Product Info

12-Digit UPC
389110787910
GTiN
03389110787917
Product UPC
78590186619
Weight
0.18 kg

Dimensions

Depth
57 mm
Height
58 mm
Warranty Length
18 mth
Width
45 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Certifications
CB Scheme,CCC,CE,CSA,EAC,UKCA,UL
Country of Origin
Indonesia
Prop 65
  • WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Compatible Products
  • LA1KN22
  • LA1KN40
  • LA1KN31
  • LA4KE1FC
  • LA1KN04
  • LA1KN13
  • LA9D90
  • LA2KT2U
