Product image for SQD LV430406 3P NSX160N WITHOUT TRI
Email

SQD LV430406 3P NSX160N WITHOUT TRI

Manufacturer: Square-D / Schneider | Catalog # LV430406 | Cooper Electric Part # 1300608
$1,407.24/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
This is a 3 poles basic frame for Compact NSX160N. Compact NSX is designed to optimize space and breaking capacity for all standard and specific applications. This basic frame comes without trip unit, and is compatible with any type of trip unit which has to be ordered separately The breaking capacity Icu is 50kA at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz (limited to 440VAC 50/60Hz if there is an earth-leakage protection). It can be equipped with a variety of optional functions and accessories. The dimensions are 105mm x 161mm x 86mm. It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX160N is part of Schneider Electric EcoStruxure Power architecture.

Technical Information

Line Rated Current
160 A
Mounting Type
Fixed
Standard
EN/IEC 60947-2,UL 508
Storage Temperature
-50-85 degrees C

Manufacturer Information

Brand
Schneider Electric

General Product Info

12-Digit UPC
785901680734
GTiN
03606480006647
Product UPC
78590168073

Dimensions

Depth
86 mm
Height
161 mm
Warranty Length
18 mth
Width
105 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CSA,UL
