WAG 218-103 MOD PCB TRM STRIPS 3POS 2.5MM W/SB

Manufacturer: Wago | Catalog # 218-103 | Cooper Electric Part # 1280183
$4.03/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times

Technical Information

Actuator
Slide
Conductor Size
20 AWG
Contact Material
Copper
Contact Type
Tin
Current
4 Amp
Flamability Class
V0
Insulation Material
Polyamide
Number of Connections
1,3
Strip Length
0.24 in
Voltage
150 Volt

Manufacturer Information

Brand
Wago

General Product Info

12-Digit UPC
044918017248
Color
Gray
Product UPC
04491801724
Weight
1.068 g

Dimensions

Depth
0.512 Inch
Height
0.429 Inch
Width
0.354 in

Certifications and Compliance

Country of Origin
Poland
Approvals
  • UL International Germany GmbH, UL, E45172, UL 1059
  • DEKRA Certification B.V., CCA, NTR NL-7785, EN 60947-7-4
  • DEKRA Certification B.V., CCA, 77-111038, EN 60947-7-4
  • DEKRA Certification B.V., ENEC, 2160584.01, EN 60947
  • DEKRA Certification B.V., CSA, 1565656, C22.2 No. 158
  • DEKRA Certification B.V., CCA, NTR NL-7076, EN 60947
Features
  • Terminal strips are just 8.1 mm tall and feature an innovative, locking slide-actuated CAGE CLAMP® .
  • Several clamping units can be held open simultaneously.
  • Easily terminate stranded conductors in tight spaces (e.g., bus connectors).
Accessory Products
  • 210-331/250-202
  • 210-331/250-204
  • 210-331/250-206
  • 210-331/250-207
  • 210-647
  • 210-719
  • 216-131
  • 216-151
  • 216-301
  • 216-321
  • 735-500
