Product image for Square D 8501CO22V14 24 VAC 4 Amp 4-Pole 2NO 2NC Panel Mount AC Operated Power Relay
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Square D 8501CO22V14 24 VAC 4 Amp 4-Pole 2NO 2NC Panel Mount AC Operated Power Relay

Manufacturer: Square-D / Schneider | Catalog # 8501CO22V14 | Cooper Electric Part # 1269702
$102.48/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page
8501C power relays are used to control VDC loads. These power relays are available with a variety of contact configurations. This relay has a DPDT contact configuration for VDC loads with two normally open and two normally closed contacts. A variety of coil voltages are available. This relay has a 24 VAC nonreplaceable coil. Designed with heavy duty contacts that are rated for 10 A resistive rating at 110 VDC or 4 A resistive rating at 220 VDC. These relays have a durable open frame construction. 8501C power relays are UL listed and CSA certified. This range of relays is used in electric heater, pumping, conveyor and material handling applications.

Technical Information

Contact Configuration
2 NO/2 NC
Number of Phases
1 Phase
Operating Temperature
-22...122 degrees F
Type
POWER RELAY

Packaging

Pkg Qty
1

Manufacturer Information

Brand
Schneider Electric
Sub Brand
TYPE C

General Product Info

12-Digit UPC
785901726807
GTiN
00785901726807
Product UPC
78590172680

Dimensions

Depth
2.53 Inch
Height
3.12 Inch
Warranty Length
18 mth
Width
2.5 in

Certifications and Compliance

CA Prop65 Warning
This product can expose you to chemicals including: Nickel compounds and Di-isodecyl phthalate (DIDP) which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.gov
Certifications
CE,CSA,UL Listed File E78351 CCN NLDX
Country of Origin
China
