Burndy BGBL250 Aluminum Lay-in Lug, 250 kcmil-#6 AWG, 7/16" Stud, Tin Plated

Manufacturer: Burndy | Catalog # BGBL250 | Cooper Electric Part # 12420
$38.95 /ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
BAA | Buy American Compliant BAA | Buy American Compliant Product Spec Sheet
Aluminum Lay-in Lug, 250 kcmil-#6 AWG, 7/16" Stud, Tin Plated.

Technical Information

Applications
For Copper And Aluminum Conductor Combinations Up To 90 DEG C, 600 Volt Applications
Bolt Size
7/16-18, 7/32 IN Hex
Conductor Material
Aluminum and Copper
Conductor Size
6 AWG-250 kcmil
Material
Aluminum
Max Voltage
600 V
Mounting Hole Size
0.28 in
Plated?
Yes
Plating Type
Tin
Stud Size
7/16-18
Temperature Rating
90 degrees C
Type
BGBL
Voltage
600 Volt

Manufacturer Information

Brand
Burndy
Sub Brand
Qiklug™

General Product Info

12-Digit UPC
781810124819
Finish
Electro-Tin Plated
GTiN
00781810124819
Product UPC
78181012481

Dimensions

Height
1.79 Inch
Hole Size
0.33 in
Length
2.2 Inch
Overall Length
2.20 in
Width
0.80 in

Certifications and Compliance

BAA | Buy American Compliant
Y
Country of Origin
Canada
CSA
Yes
Features
  • UL486B Listed, AL9CU Rated for copper and aluminum conductor combinations up to 90°C
  • UL Recognized for grounding and bonding
  • Lay-in feature eases installation
