3M 7000006104 Cold Shrink QT-III Termination Kit 7693-T-150, Tape/Wire/UniShield® Shielding, 5-35 kV, Indoor (1kit/case)

Manufacturer: 3M | Catalog # 7000006104 | Cooper Electric Part # 121819
$2,351.13 /ea
kt
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Ocean opens monday 7:00am et
5 available

For Delivery

Order by Monday 5:00pm ET for delivery Tuesday
Not in local stock *
Check another branch
Product Brochure Product Catalog Page Product Spec Sheet Safety Data Sheet
3M™ Cold Shrink QT-III Termination Kits offer easy installation and reliable performance when terminating indoor and outdoor medium voltage cable. The Hi-K stress control design delivers excellent BIL performance and lower surface stress, resulting in a more compact termination. The 3M™ Cold Shrink QT-III Termination Kit 7693-T-150 has a conductor size range for 5 kV: 300-500 kcmil, 8 kV: 250-500 kcmil, 15 kV: 2/0 AWG-300 kcmil, 25/28 kV: 2-4/0 AWG and 35 kV: 2-2/0 AWG.

Technical Information

Applications
For Terminating Solid Dielectric Shielded Power Cable, Tape Shield, Wire Shield and UniShield® Constructions, Free-Hanging or Bracket-Mounting Arrangements, Compact Design Provides for Easier Installation in Restricted Spaces, Indoor and Protected Areas
Cable Type
Tape Shield; UniShield(R); Wire Shield
Conductor Size
1 AWG-500 kcmil
Indoor Outdoor
Indoor Non-skirted
Material
Rubber
Type
QT-III
Voltage
15 kV

Manufacturer Information

Brand
3M

General Product Info

12-Digit UPC
054007417781
GTiN
00054007417781
Product Series
7690-T
Product UPC
05400741778
Used With
0.72 - 1.29 in Cable, QL2-A-2-250 Lug

Certifications and Compliance

Country of Origin
USA
Features
  • Provides a void-free seal to tape shield, wire shield and UniShield® power cables
  • High dielectric-constant material regulates the distribution of electric field stress
  • Suitable for indoor applications
  • Non-tracking, molded, silicone rubber insulation offers durability
  • Includes 3 non-skirted, 1-piece, 3-phase, cold shrink terminations
