WAG 231-302/026-000 MOD F-CONN W/C-C

Manufacturer: Wago | Catalog # 231-302/026-000 | Cooper Electric Part # 1212368
$3.98/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
WAG 231-302/026-000 MOD F-CONN W/C-C

Technical Information

Actuator
Operating Tool
Conductor Size
12 AWG
Connection Type
For Conductor
Contact Material
Copper Alloy
Contact Type
Tin
Current
15 Amp
Flamability Class
V0
Insulation Material
Polyamide
Number of Connections
1,2
Strip Length
0.35 in
Voltage
300 Volt

Manufacturer Information

Brand
Wago

General Product Info

12-Digit UPC
044918024796
Color
Orange
Product UPC
04491802479
Weight
3.877 g

Dimensions

Depth
1.041 Inch
Height
0.563 Inch
Width
0.459 in

Certifications and Compliance

Country of Origin
Germany
Features
  • Universal connection for all conductor types
  • Easy cable pre-assembly and on-unit wiring via vertical and horizontal CAGE CLAMP® actuation
  • Integrated test ports
  • With coding fingers
Approvals
  • DEKRA Certification B.V., CB, NL-39756/A1, EN 61984
  • WAGO GmbH & Co. KG, Railway, Railway Ready
  • DEKRA Certification B.V., CB, NL-39756/A1, IEC 61984
  • Underwriters Laboratories Inc., UR, E45172, UL 1059
  • UL International Germany GmbH, UL, E45171, UL 1977
  • DEKRA Certification B.V., KEMA/KEUR, 71-121453, EN 61984
  • American Bureau of Shipping, ABS, 19-HG1869876-PDA
  • DEKRA Certification B.V., CSA, 1466354, C22.2
