Product image for TES Sensors 9007AW38 Limit switch, 9007, 600 VAC 10amp aw +options
Image thumbnail 0
Image thumbnail 1
Email

TES Sensors 9007AW38 Limit switch, 9007, 600 VAC 10amp aw +options

Manufacturer: TES Electric | Catalog # 9007AW38 | Cooper Electric Part # 1200493
$522.90/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page Product Brochure
Limit switch, 9007, 600 VAC 10amp aw +options

Technical Information

Action
BY 30A? CAM,SNAP ACTION,TRAVERSE APPROACH, 2 DIRECTIONS
Actuator
CAST ZINC,PLUNGER HEAD,SPRING RETURN ROLLER PLUNGER STEEL WITH MICROMETER ADJUSTMENT
Amperage
10 Amp
Applications
PRECISION
Body Material
Cast Zinc
Body Type
Fixed NULL
Cable Entry
1 entry for 1/2" - 14 NPT ANSI B1.20.1
Contact Configuration
2(NC-NO) DPDT-DB
Contact Material
Silver
Enclosure
NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 12 NEMA TYPE 250-NEMA 13 NEMA TYPE 250
Material
Metal
Mounting Type
Surface Mounting Deep Box
Net Weight
1.25 lb
Number of Poles
2 Pole
Number of Steps
1
Operating Temperature
0-185 degrees F
Size
1.44 IN,2.53 IN,3.68-3.68 IN
Storage Temperature
0-185 degrees F
TC Connection
1-2 SCREW-CLAMP TERMINALS AWG 22...AWG 12)
Type
LIMIT SWITCH
Voltage
0.6 A 600 Volt AC, B600 NEMA RATING DESIGNATION-0.75 A 480 Volt AC, B600 NEMA RATING DESIGNATION-1.5 A 240 Volt AC, B600 NEMA RATING DESIGNATION-3 A 120 Volt AC, B600 NEMA RATING DESIGNATION-0.1 A 250 Volt DC-0.2 A 125 Volt DC

Manufacturer Information

Brand
Telemecanique
Sub Brand
9007AW

General Product Info

12-Digit UPC
785901830221
GTiN
00785901830221
Product UPC
78590183022
Weight
1.25 lb

Dimensions

Depth
1.44 Inch
Height
3.68-3.68 Inch
Warranty Length
18 mth
Width
2.53 in

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Country of Origin
Mexico
