Product image for ILSCO CSWD-600-12-1 CU CMP 600 kcm
Image thumbnail 0
Image thumbnail 1
Email

ILSCO CSWD-600-12-1 CU CMP 600 kcm

Manufacturer: Ilsco | Catalog # CSWD-600-12-1 | Cooper Electric Part # 1159008
$42.16 /ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
Surecrimp Copper Compression Lug, Copper material, Tin plated connector,Standard barrel, standard tang, 2 mounting hole(s), mounting bolt/stud size 1/2 in, mounting hole spacing 1 in., UL 486A/B Listed, C22.2 No. 65-03, 180. connecting angle, Copper Primary Conductor 600 kcmil, sight window, Square tang end, flex conductor range 400 G,H,I,K,M 444.4 DLO, rated for 35 kV, die color code Green, primary color Silver, die index I-94,

Technical Information

Applications
Copper Compression Lug
Barrel Length
1.375 in
Barrel Type
Standard
Conductor Material
Copper
Conductor Type
Flex,Stranded
Connection Type
Compression
Direct Burial?
No
Material
Copper
Mounting Hole Size
0.562 in
Number of Holes
2 Hole
Size
L:4.309;W:1.712;H:1.233 IN
Strip Length
36.499 mm
Temperature Rating
90 degrees C
Type
CSWD:2 HOLE SHORT W/SIGHT
Voltage
35 Volt

Manufacturer Information

Brand
Ilsco
Sub Brand
Surecrimp

General Product Info

12-Digit UPC
783669647051
Color
Green,Silver
GTiN
00783669647051
Product UPC
78366964705
Weight
0.563 lb

Dimensions

Height
1.233 Inch
Inside Diameter
0.92 in
Length
4.39 Inch
Outside Diameter
1.188 in
Width
1.712 in
