Product image for Mersen TRM1/4 13/32 x 1-1/2 Inch 1/4 Amp 250 Volt Time Delay Midget Fuse
Email

Mersen TRM1/4 13/32 x 1-1/2 Inch 1/4 Amp 250 Volt Time Delay Midget Fuse

Manufacturer: Mersen | Catalog # TRM1/4 | Cooper Electric Part # 114482
$20.73/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
Tri-Onic® TRM time-delay midget fuses are rated 250 volts AC and are offered in ampere ratings from 1/10 to 30A. They have 12 seconds time-delay at 200% rating to provide supplemental protection of small motors, small transformers and other high inrush loads, plus many other 250 volt applications. (Not for Branch Circuit Protection).

Technical Information

Amperage
0.25 Amp
Applications
Small Motors Small Transformers Lighting Circuits Control Circuits
Contact Material
Tin-Plated Copper
Fuse Class
Midget
Insulation Material
GMG
Interrupt Rating
10 kAIC
Mounting Type
Clip
Rated Voltage AC
250 V
TC Connection
Ferrule
Terminal Material
Tin-Plated Copper
Terminal Type
Ferrule
Type
Supplemental Protection
Voltage
250 VAC

Packaging

Pkg Qty
10

Manufacturer Information

Brand
Ferraz Shawmut Canada, Inc.

General Product Info

12-Digit UPC
782001741037
Class
M
GTiN
30782001741038
Product UPC
78200174103
Weight
0.012 lb

Dimensions

Diameter
0.41 Inch
Length
1-1/2 Inch
Features
  • Numerous ratings for a wide variety of applications
  • 250VAC rating in all sizes up to 30A
  • Time-delay for circuits with high inrush currrent
  • Can be used with UltraSafeTM fuse holders
  • 1 1/2\" x 13/32\" (10mm x 38mm) dimensions
Applications
  • Small motors
  • Small transformers
  • Lighting circuits
  • Control circuits
Approvals & Standards
  • UL listed to standard 248-14 File E33925
  • CSA Certified to Standard C22.2 No. 248.14
