Satco S9750 30W - LED HID Replacement; 5000K; Medium base; Adjustable beam angle; 100-277 Volt

Manufacturer: Satco | Nuvo | Catalog # S9750 | Cooper Electric Part # 1133946
$100.68/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
30 watt - LED HID Replacement; 5000K; Medium base; Adjustable beam angle; 100-277 volts

Technical Information

Amperage
0.300-0.108 Amp
ANSI Base
E26
Applications
High Bay, Low Bay and Post Top Fixtures
Average Rated Life
50000 hr
Base
Medium
Beam Angle
360
Beam Spread
360
Bulb Shape
Corncob
Color Accuracy
83
Color Rendering Index
83
Color Temperature
5000 K
Correlated Color Temp
5000 K
Dimmable?
No
Incandescent Equivalent
200 W
IP Rating
IP65
Lens Color
Clear
Lumens
3,900 Lumen
Operating Temperature
-20 degrees C
Power Factor
0.9
Technology Type
LED
Temperature Rating
-20 to 65 degrees C
Type
Corncob
Voltage
100 Volt
Wattage
30 Watt
Wet Location
Damp

Packaging

Pkg Qty
1

Manufacturer Information

Brand
Satco
Sub Brand
Hi-Pro

General Product Info

12-Digit UPC
045923097508
Finish
Clear
GTiN
00045923097508
Housing Color
White
Product UPC
04592309750
Weight
1.62 lb

Dimensions

Diameter
3.13 Inch
Warranty Length
5 yr

Certifications and Compliance

Country of Origin
China
Installation Notes
  • Not for use in vapor tight fixtures. Arms fully open diameter is 7.69 inches
Ballasting Requirements
  • Ballast Bypass
Features
  • Width 360 deg 3.2 in.
  • Width 270 deg 6.8 in.
  • Width 180 deg 7.7 in.
