Product image for Hubbell HBL1259I SP PRESSSWITCH, 15A, IL, IV
Email

Hubbell HBL1259I SP PRESSSWITCH, 15A, IL, IV

Manufacturer: Hubbell Wiring Device | Catalog # HBL1259I | Cooper Electric Part # 1132616
$204.40/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page
Switches and Lighting Controls, Illuminated Industrial Grade, PresSwitch, General Purpose AC, Four Way, 15A 120/277V AC, Screw Terminals , Ivory

Technical Information

Action
DPDT
Actuator
Push Button
Amperage
15 Amp
Applications
For Heavy-Duty Industrial, Switches and Lighting Controls
Conductor Size
14-10 AWG
Connection Type
Screw Terminal
Contact Configuration
Two Position
Current
15 Amp
Indicator
Illuminated
Material
Thermoset
Number of Poles
1-1 Pole
Operating Cycles
10k
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
Fed. Spec. W-S-896
Style
Four Way
Switch Type
DPDT
TC Connection
Terminal Screws
Temperature Rating
-40 to 75 degrees C
Type
4-Way, 1-Pole, 2-Position, Illuminated Industrial Grade, Pushbutton, Standard
Voltage
120 Volt
Wattage
1800 Watt
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Switches and Lighting Controls

General Product Info

12-Digit UPC
783585016801
Color
Ivory
Environmental Conditions
Indoor Dry unless protected by additional means
GTiN
00783585016801
Product Series
Illuminated
Product UPC
78358501680

Dimensions

Height
1.45 Inch
Length
3.28 Inch
Width
1.5 in

Certifications and Compliance

Country of Origin
USA
Features
  • Large brass binding head screws with deep slots
  • Thread cleaning captive mounting screw
  • Strip gauge for accurate wiring
