SQD LV431670 3P3T TM250T NSX250H

Manufacturer: Square-D / Schneider | Catalog # LV431670 | Cooper Electric Part # 1126938
$2,311.80/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
This Compact NSX250H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 250A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX250H is part of Schneider Electric EcoStruxure Power architecture.

Technical Information

Line Rated Current
250 A
Mounting Type
Fixed
Net Weight
2.4 kg
Standard
EN/IEC 60947
Storage Temperature
-50-85 degrees C

Manufacturer Information

Brand
Schneider Electric

General Product Info

12-Digit UPC
785901161257
GTiN
03606480014468
Product UPC
78590116125

Dimensions

Depth
86 mm
Height
161 mm
Warranty Length
18 mth
Width
105 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Certifications
CCC,EAC,Marine
