Product image for Cutler-Hammer XTCEC015B01TD XT IEC contactor, 15A, 24 Vdc, 1NC, 15A, Frame B, 45 mm, 1, 2, 3/ 5, 5, 10, 10 hp (1/3PH @115, 200, 230/200, 230, 460, 575 V), DILMC15-01, Three-pole, Non-reversing, , Spring
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Image thumbnail 4
Email

Cutler-Hammer XTCEC015B01TD XT IEC contactor, 15A, 24 Vdc, 1NC, 15A, Frame B, 45 mm, 1, 2, 3/ 5, 5, 10, 10 hp (1/3PH @115, 200, 230/200, 230, 460, 575 V), DILMC15-01, Three-pole, Non-reversing, , Spring

Manufacturer: Cutler-Hammer / Eaton | Catalog # XTCEC015B01TD | Cooper Electric Part # 1124405
$188.98/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page
Eaton XT IEC contactor, 15A, 24 Vdc, 1NC, 15A, Frame B, 45 mm, 1, 2, 3/ 5, 5, 10, 10 hp (1/3PH @115, 200, 230/200, 230, 460, 575 V), DILMC15-01, Three-pole, Non-reversing, , Spring cage terminals, FVNR

Technical Information

Amperage
15 Amp
Coil Voltage
24 V
Contact Configuration
1 NC
Frame
45 mm
Number of Poles
3 Pole
Standard
CSA,E2186,UL
Terminal Type
Spring Cage Terminals
Type
Contactors

Manufacturer Information

Brand
Eaton
Sub Brand
None

General Product Info

12-Digit UPC
015082939612
GTiN
04015082939618
Product UPC
01508293961
Weight
.63 lb

Dimensions

Height
2.68 Inch
Length
2.95 Inch
