SQUARED RMPT33BD Converter for Opti

Manufacturer: Square-D / Schneider | Catalog # RMPT33BD | Cooper Electric Part # 1110016
$134.07/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
This temperature transmitter is part of the range of Harmony Analog interfaces. It is designed to convert signal of Pt100 probe into standard electrical signal which is compatible with automation platforms, controllers. Its supply voltage is 24V DC, non isolated. It also allows the connection distance between a sensor and the measurement acquisition device to be increased. The cables used to connect the converters to process equipment (PLCs) are standard cables, which are more cost effective than extension cables or compensation cables suitable for low level signals for Pt100 probes or thermocouples. Conforming to IEC standards, UL and CSA certified, this converter is suitable for universal use. 0 0 0 0 0 0 0 0 0 0

Technical Information

Current
40 mA
Enclosure
IP20 TERMINAL BLOCK)-IP50 HOUSING)
Net Weight
0.12 kg
Operating Temperature
0-50 degrees C Mounting Side By Side || 0-60 degrees C 2 Cm Spacing
Output
-15...-11 V NO INPUT OR INPUT WIRE BROKEN-11...15 V NO INPUT OR INPUT WIRE BROKEN,-30-0 MA NO INPUT OR INPUT WIRE BROKEN-22-30 MA NO INPUT OR INPUT WIRE BROKEN,CURRENT 4...20 MA <= 500 OHM-VOLTAGE 0...10 V >= 100 KOHM
Power Supply
24 V DC NON ISOLATED +/- 20 ,<= 40 MA VOLTAGE OUTPUT-<= 60 MA CURRENT OUTPUT
Standard
DIN 43760,IEC 60584-1,IEC 60751,IEC 60947-1
Storage Temperature
-40-85 degrees C
Temperature Rating
0-50 A?degrees C MOUNTING SIDE BY SIDE-0-60 A?degrees C 2 CM SPACING
Type
Converter for Optimum Pt100 probes

Manufacturer Information

Brand
Schneider Electric

General Product Info

12-Digit UPC
785901566205
GTiN
03389110108972
Product UPC
78590156620
Weight
0.12 kg

Dimensions

Warranty Length
18 mth

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CSA,GL,UL
Country of Origin
Indonesia
Prop 65
  • WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Cross Sell Products
  • RMPT30BD
  • RMPT23BD
  • RMPT53BD
