Product image for SQD XCSL582B2 INTERLOCK SWITCH 300V
Image thumbnail 0
Image thumbnail 1
Email

SQD XCSL582B2 INTERLOCK SWITCH 300V

Manufacturer: Square-D / Schneider | Catalog # XCSL582B2 | Cooper Electric Part # 1100944
$466.00/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet
INTERLOCK LIMIT SWITCH 300 VAC 10 AS XCSL

Technical Information

Action
SLOW-BREAK, BREAK BEFORE MAKE
Amperage
4 Amp
Applications
KEY OPERATED TURRET HEAD
Contact Configuration
1 NC + 1 NO,1 NC + 1 NO SLOW-BREAK, BREAK BEFORE MAKE)
Material
Plastic
Number of Poles
2 Pole
Operating Cycles
10 cyc/mn For Maximum Durability
Operating Temperature
-25-60 Adegrees C
Size
205-205 MM,44 MM,51 MM
Standard
CSA C22.2 No 14,EN 1088/ISO 14119,EN/IEC 60204-1,EN/IEC 60947-5-1,EN/IEC 62061,EN/ISO 13849-1,UL 508
TC Connection
SPRING TERMINAL 1 X 1.5 MMA FLEXIBLE OR SOLID CABLE-SPRING TERMINAL 2 X 0.5 MMA FLEXIBLE CABLES WITH 13 MM BARED ENDS
Type
KEY OPERATED TURRET HEAD,SAFETY SWITCH
Voltage
0.55 A 24 Volt, DC-13, R300 EN/IEC 60947-5-1-0.75 A 240 Volt, AC-15, R300 EN/IEC 60947-5-1,24 Volt-15...10

Manufacturer Information

Brand
Preventa
Sub Brand
XCSLE

General Product Info

12-Digit UPC
389110958228
GTiN
03389110958225
Product UPC
38911095822
Weight
1.17 lb

Dimensions

Chain Cable Diameter
0.51 in
Depth
2.01 Inch
Height
8.07 Inch
Warranty Length
18 mth
Width
1.73 in

Certifications and Compliance

CA Prop65 Warning
This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP) and Diisononyl phthalate (DINP) which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.gov
Certifications
CSA,TV,UL
Country of Origin
France
