Product image for 3M Industrial Safety MNG10-250DMIX Nylon Insulated 50/Bottle Male Disconnect
Email

3M Industrial Safety MNG10-250DMIX Nylon Insulated 50/Bottle Male Disconnect

Manufacturer: 3M | Catalog # 7000133358 | Cooper Electric Part # 1097505
$2.59/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page
3M™ Scotchlok™ Male Disconnect is an insulated disconnect which attaches to its mating part by slipping the tongue of the male part over the female tab. This disconnect offers superior holding force while allowing for quick and easy disconnect. Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion. The terminal has a fully insulated, nylon, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). 3M™ Scotchlok™ Male Disconnects are UL Recognized and CSA certified.

Technical Information

Barrel Type
Butted
Conductor Size
10 AWG
Insulation Material
Nylon,Insulation Grip
Material
Plastic
Max Operating Temperature
105.0 degrees C
Tab Size
6.3 x 0.8 mm
Terminal Size
12 - 10 AWG
Terminal Style
Fully Insulated
Terminal Type
Disconnect
Type
Disconnect

Manufacturer Information

Brand
Scotchlok
Sub Brand
Scotchlok

General Product Info

12-Digit UPC
051128587935
Color
Yellow
GTiN
00051128587935
Product UPC
05112858793

Dimensions

Diameter
0.39 Inch
Length
1.05 Inch
Overall Length
1.05 in
Thickness
0.032 in
Width
0.47 in

Certifications and Compliance

Country of Origin
USA
Features
  • This male disconnect terminal offers excellent holding force
  • Allows for quick and easy disconnect of wires
  • Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
