Blackburn 2B500X 2-Bolt Clamp

Manufacturer: Blackburn / Thomas & Betts | Catalog # 2B500X | Cooper Electric Part # 1096198
$8,831.84/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page
Copper Type 2BX - One piece Two-Bolt Connector without spacer for Wire Range Main: 300 - 500 kcmil Tap: 4 Sol. - 500 kcmil , Bolt Size 3/4

Technical Information

Bolt Size
3/4 in
Conductor Size
300 - 500 kcmil Main/Primary, 4 AWG Solid - 500 kcmil Tap/Secondary
Material
Copper
Standard
UL E9809
Stud Size
3/4 in
Type
1-Piece

Manufacturer Information

Brand
Thomas & Betts (T&B)
Sub Brand
Blackburn®

General Product Info

12-Digit UPC
783786400126
GTiN
00783786400126
Product UPC
78378640012

Dimensions

Outside Diameter
3/4 in
Features
  • Single-piece construction. Castings and bolts of high-strength copper alloy. Neoprene washer holds free bolt in place during installation.
  • UL 486A listed for copper conductor only.
