Product image for Square D LC2K12107B7 575 VAC 12 Amp 3-Pole 1NO Slip-On Terminal Full Voltage Reversing IEC Contactor
Image thumbnail 0
Image thumbnail 2
Image thumbnail 3
Image thumbnail 4
Image thumbnail 5
Email

Square D LC2K12107B7 575 VAC 12 Amp 3-Pole 1NO Slip-On Terminal Full Voltage Reversing IEC Contactor

Manufacturer: Square-D / Schneider | Catalog # LC2K12107B7 | Cooper Electric Part # 1086871
$223.13 /ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Catalog Page CAD Drawing #1 CAD Drawing #2 Product Spec Sheet CAD Drawing #3
TeSys K contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (4kW@440V), and for non-inductive load control applications up to 20A/690V AC-1. It provides a 24V 50/60Hz AC coil,1NO built-in auxiliary contact, connection by faston connectors. For operating rates until 600 cycles/hour and environments until 50.C, it procures reliability and durability to standard applications. With feature (90mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC).

Technical Information

Applications
CONTROL,RESISTIVE LOAD-MOTOR CONTROL
Coil Voltage
24 V AC 50/60 HZ,POWER CIRCUIT 690 V AC 50/60 HZ-SIGNALLING CIRCUIT <= 690 V AC 50/60 HZ
Contact Configuration
1 NO,3 NO
Contact Rating
20 A 50 AC POWER CIRCUIT-10 A 50 AC SIGNALLING CIRCUIT
Impedance
3 MOhm - Ith 20 A 50 Hz For Power Circuit
Net Weight
0.39 kg
Operating Cycles
3600 cyc/h
Operating Temperature
-25-50 Adegrees C
Range
TeSys NULL
Size
57 MM,58 MM,90 MM
Standard
CSA C22.2 No 60947-4-1,EN/IEC 60947-4-1,GB/T 14048.4,JIS C8201-4-1,UL 60947-4-1
Storage Temperature
-50-80 degrees C
TC Connection
FASTON TERMINALS 2 2.8 MM- FASTON TERMINALS 1 6.35 MM
Type
Reversing contactor
Voltage
690 Volt

Manufacturer Information

Brand
Schneider Electric
Sub Brand
TESYS K

General Product Info

12-Digit UPC
338911084971
GTiN
03389110849783
Product UPC
78590142069
Weight
0.39 kg

Dimensions

Depth
2.24 in
Height
2.28 in
Warranty Length
18 mth
Width
3.54 in

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Certifications
CB Scheme,CCC,CE,CSA,EAC,UKCA,UL
Country of Origin
France
Prop 65
  • WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
