Thomas & Betts 18RA-4 #4 Bolt Hole 22-16 AWG Red Wire Range Insulated Vinyl Ring Terminal

Manufacturer: ABB | Thomas & Betts | Catalog # 18RA-4 | Cooper Electric Part # 1066251
$203.71/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Product Brochure
Vinyl-Insulated Ring Terminal, Length .97 Inches, Width .31 Inches, Maximum Insulation .150, Bolt Hole #4, Wire Range #22-#18 AWG, Color Red, Copper, Tin Plated

Technical Information

Barrel Type
Brazed Seam
Conductor Size
22-16 AWG
Flamability Class
Rated V-0 Per UL94
Insulation Material
Vinyl
Insulation Type
Insulated Vinyl
Material
Copper
Standard
UL E9809
Stud Size
#4
Temperature Rating
105 degrees C
Terminal Type
RA
Type
Short Sleeve
Voltage
600 Volt
Wire Size
22-16 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210800820
Color
Red
Finish
Electro Tin Plated
GTiN
05414363138532
Product UPC
78621080082

Dimensions

Height
7.2 Inch
Thickness
.03 in
Width
8.7 in
Features
  • These terminals are self-insulated with a PVC insulation sleeve of extra length to give protection and relieve bending stress at wire's flex point. Brazed seam barrel is serrated to obtain high pull-out value.
Certifications
  • UL
  • CSA
