Caddy CRLM37EG Quick 3/8" Metal Decking Preset Anchor with Push-to-Install Technology - 830LB

Manufacturer: Erico, Inc | Catalog # CRLM37EG | Cooper Electric Part # 1060375
$1,326.52/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Product Brochure
Innovative preset anchors for metal decking, designed to simplify installation of threaded rod assemblies thanks to the nVent CADDY Rod Lock push-to-install technology. Ideal for prefabrication. Push-to-install technology, female threaded 3/8"-16.

Technical Information

Applications
Acoustical, Datacom, Electrical, Fire, HVAC, Seismic
Load Capacity
830 lb
Material
Steel
Type
CADDY ROD LOCK Threaded Rod Mounting System

Packaging

Standard Packaging Qty
25/Pack

Manufacturer Information

Brand
nVent Caddy
Sub Brand
CADDY

General Product Info

12-Digit UPC
782856793885
Finish
Electro Galvanized
GTiN
00782856793885
Product UPC
78285679388
Weight
0.17 kg

Dimensions

Diameter
0.7 Inch
Length
5.6 Inch
Certifications
  • FM Approved, Pipe Hanger Components FM 1951, 1952, 1953 (December 2016)
  • ICC-ES AC446
Features
  • Set in place through a drilled hole in the metal decking before the concrete is poured
  • Eliminate overhead drilling into building structure - nVent CADDY Rod Lock Preset Anchors are cast in place
  • Easy \"push-to-install\" design allows installers to simply push the threaded rod through the mounting hole, instantly holding it in position
  • Can be used in lower and upper flute installations
  • Works with slightly damaged threads and minor burrs on the threaded rod
  • Prefabricated assemblies easily lift and lock into place, helping to save time and money
  • Plastic flange acts as insert locator when the forms are removed
  • Rated for cracked concrete per ICC-ES AC446 according to ICC-ES ESR-3864 evaluation report
  • Suitable for seismic bracing according to ICC-ES ESR-3864 evaluation report
