Square D CA2KN40FC72 36 VAC 10 Amp 4.5 VA 4-Pole 4NO IEC Control Relay

Manufacturer: Square-D / Schneider | Catalog # CA2KN40FC72 | Cooper Electric Part # 1055020
$90.65/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
Control relay, TeSys K, 4 NO, lt or eq to 690V, 36VAC coil

Technical Information

Amperage
10 Amp AT <= 50 ?C
Applications
Control circuit
Contact Configuration
4 NO
Contact Rating
<= 690 V <= 400 HZ
Enclosure
IP2X
Net Weight
0.18 kg
Operating Cycles
10000 cyc/h
Operating Temperature
-25-50 Adegrees C
Size
2.24 in
Standard
CSA C22.2 No 60947-4-1,EN/IEC 60947-4-1,GB/T 14048.4,JIS C8201-4-1,UL 60947-4-1
Storage Temperature
-50-80 degrees C
TC Connection
SCREW CLAMP TERMINALS 1 1.5-4 MMASOLID- SCREW CLAMP TERMINALS 2 1.5-4 MMASOLID- SCREW CLAMP TERMINALS 1 0.75-4 MMAFLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.75-4 MMAFLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 0.34-1.5 MMAFLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.34-1.5 MMAFLEXIBLE WITHOUT CABLE END
Type
Control relay
Voltage
690 Volt

Manufacturer Information

Brand
Schneider Electric
Sub Brand
CA2K;TeSys CAK

General Product Info

12-Digit UPC
785901142881
GTiN
03389110840575
Product UPC
78590114288
Weight
0.18 kg

Dimensions

Depth
57 mm
Height
58 mm
Warranty Length
18 mth
Width
45 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Certifications
CB Scheme,CCC,CE,CSA,EAC,UKCA,UL
Country of Origin
Indonesia
Prop 65
  • WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Compatible Products
  • LA1KN22
  • LA1KN40
  • LA1KN31
  • LA1KN04
  • LA1KN13
  • LA9D90
  • LA2KT2U
