P&S 2095-NABK 20A 125V GFCI RCPT

Manufacturer: Pass & Seymour / Legrand | Catalog # 2095-NABK | Cooper Electric Part # 1051551
$40.01/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
From the innovator of the product category, comes a full range of Pass & Seymour GFCI receptacles to enhance safety, shorten installation times and increase productivity on the jobsite. This GFCI meets the requirements of the Buy American provision of the American Recovery and Reinvestment Act and provides the same protection as our traditional GFCI.

Technical Information

Amperage
20 Amp
NEMA
5-20R
Voltage
125 Volt

Manufacturer Information

Brand
Pass & Seymour
Sub Brand
adorne

General Product Info

12-Digit UPC
785007006766
Color
Black
Product UPC
78500700676

Dimensions

Depth
1.13 Inch
Height
4.2 Inch
Length
4.2 Inch
Width
1.72 in
Features & Benefits
  • GFCIs with Auto-Ground assure a positive ground to metal box.
  • Trip indicator light (red LED).
  • 10kA short circuit rating.
  • High-impact-resistant thermoplastic construction.
  • Tri-drive screws.
  • NAFTA-Compliant GFCI Receptacles are ideal for use on projects subject to the provisions of the Buy American Act.
  • Button colors match the device face.
  • FSUL Listed (Federal Specification WC596).
  • SafeLock™ Protection: if critical components are damaged and ground fault protection is lost, power to receptacle is disconnected.
  • Ground screw has a back wire clamp for easy installation.
  • For covering patents, see www.legrand.us/patents.
  • Side or internal screw-pressure-plate back wire with #10 #14 AWG solid or stranded copper wire.
  • Mounting screws are shipped captive in the device and wall plate for easier installation.
  • Exceeds UL943 voltage surge requirements; survives 100x the required UL 3kA/6kV voltage surge test cycles.
  • Supplied with matching TP26 nylon wall plate.
  • 1/4\" thinner than competitors' GFCIs; leaves more room for wires in the box.
  • Dual-direction test and reset buttons.
  • Prevents line-load reversal miswire: no power to the face or downstream receptacles if wired incorrectly.
  • Class A rated GFCI.
  • Two back wire holes per terminal.
  • Extra-long strap.
Available Options
  • NAFTA-Compliant TradeMaster®/Spec-Grade 20A Duplex GFCI, Brown
  • NAFTA-Compliant TradeMaster®/Spec-Grade 20A Duplex GFCI, Ivory
  • NAFTA-Compliant TradeMaster®/Spec-Grade 20A Duplex GFCI, Gray
  • NAFTA-Compliant TradeMaster®/Spec-Grade 20A Duplex GFCI, Red
  • NAFTA-Compliant TradeMaster®/Spec-Grade 20A Duplex GFCI, White
  • NAFTA-Compliant TradeMaster®/Spec-Grade 20A Duplex GFCI, Black
  • NAFTA-Compliant TradeMaster®/Spec-Grade 20A Duplex GFCI, Light Almond
  • NAFTA-Compliant TradeMaster®/Spec-Grade 20A Duplex GFCI, Blue
