Applications
MOTOR CONTROL-RESISTIVE LOAD
Coil Voltage
48 V DC,POWER CIRCUIT <= 690 V AC 25...400 HZ
Contact Configuration
1 NO + 1 NC,3 NO
Contact Rating
10 A 60 AC CONTROL CIRCUIT-60 A 60 AC POWER CIRCUIT
Operating Cycles
3600 CYC/H 60 AC
Operating Temperature
-40-70 Adegrees C AT UC,-5-60 Adegrees C
Standard
CSA C22.2 No 14,EN 60947-4-1,EN 60947-5-1,IEC 60947-4-1,IEC 60947-5-1,UL 508
TC Connection
CONTROL CIRCUIT SCREW CLAMP TERMINALS 1 1-4 MMARIGID-CONTROL CIRCUIT SCREW CLAMP TERMINALS 2 1-4 MMARIGID-CONTROL CIRCUIT SCREW CLAMP TERMINALS 1 1-4 MMAFLEXIBLE WITHOUT CABLE END-CONTROL CIRCUIT SCREW CLAMP TERMINALS 2 1-4 MMAFLEXIBLE WITHOUT CABLE END-CONTROL CIRCUIT SCREW CLAMP TERMINALS 1 1-2.5 MMAFLEXIBLE WITH CABLE END-CONTROL CIRCUIT SCREW CLAMP TERMINALS 2 1-2.5 MMAFLEXIBLE WITH CABLE END-POWER CIRCUIT SCREW TERMINALS 1 2.5-25 MMARIGID-POWER CIRCUIT SCREW TERMINALS 2 2.5-16 MMARIGID-POWER CIRCUIT SCREW TERMINALS 1 2.5-25 MMAFLEXIBLE WITHOUT CABLE END-POWER CIRCUIT SCREW TERMINALS 2 2.5-16 MMAFLEXIBLE WITHOUT CABLE END-POWER CIRCUIT SCREW TERMINALS 1 2.5-25 MMAFLEXIBLE WITH CABLE END-POWER CIRCUIT SCREW TERMINALS 2 2.5-10 MMAFLEXIBLE WITH CABLE END
Wattage
12 Watt 48 Volt DC-13 10000000 CYCLES - CONTROL CIRCUIT-38 Watt 48 Volt DC-13 3000000 CYCLES - CONTROL CIRCUIT-76 Watt 48 Volt DC-13 1000000 CYCLES - CONTROL CIRCUIT5.4 Watt AC-1 - 2.4 Watt AC-3
CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.p65warnings.ca.gov
Certifications
BV,CB,CCC,CSA,DNV,GL,GOST,LROS (Lloyds Register Of Shipping),RINA,UKCA,UL
