Product image for Square D GS2SU3 600 VAC 600 Amp 3-Pole Manual Starter Enclosure Copper Fusible Disconnect Switch
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Square D GS2SU3 600 VAC 600 Amp 3-Pole Manual Starter Enclosure Copper Fusible Disconnect Switch

Manufacturer: Square-D / Schneider | Catalog # GS2SU3 | Cooper Electric Part # 1025303
$4,766.03/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
TeSys GS fuse switch-disconnector, 3 poles (3P), 600A/1000V, to be used with class J fuse links up to 600A, for motor applications up to 355kW@400V AC-23. To be equipped with an external front side mounting operating handle GS2AH (several models available). Screw terminals to be equipped with upstream and downstream 3P terminal shrouds GS1AP73 (to be ordered separately), it provides high short circuit current rating 200kA@600V. Add-on auxiliary contact modules, front mounting GS1AM (early-break and position signaling), side mounting GS1AN (position signaling) can complete the assembly (to be ordered separately). UL/CSA certified, Green Premium compliant (RoHS/REACh).

Technical Information

Amperage
600 Amp AC-22A-600 Amp AC-23A
Applications
GS2S
Contact Configuration
3 NO
Enclosure
IP20 WITH TERMINAL COVER CONFORMING TO IEC 60529
Fuse Type
UL
Net Weight
29 kg
Number of Poles
3 Pole
Operating Temperature
-20-70 Adegrees C
Range
TeSys
Size
250 MM,300 MM,364 MM
Standard
CSA C22.2 No 4,UL98
Storage Temperature
-40-80 degrees C
TC Connection
POWER CIRCUIT LUGS-RING TERMINALS 2 150-150 MMA-POWER CIRCUIT BARS 100-100 MMA
Type
SWITCH-DISCONNECTOR-FUSE

Manufacturer Information

Brand
Schneider Electric
Sub Brand
GS2S,TESYS GS

General Product Info

12-Digit UPC
389119411441
GTiN
03389119411448
Product UPC
78590155049
Weight
29 kg

Dimensions

Depth
250 mm
Height
300 mm
Warranty Length
18 mth
Width
364 mm
