Product image for Thomas & Betts C10-14 Non-Insulated Ring Terminal - #12-10, 1/4"bolt
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Thomas & Betts C10-14 Non-Insulated Ring Terminal - #12-10, 1/4"bolt

Manufacturer: ABB | Thomas & Betts | Catalog # RC10-14 | Cooper Electric Part # 102200
$442.90 /c (100 ea)
ea
Order in multiples of 50 (pack qty)
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Ocean Closes 5:00PM ET
200 available

For Delivery

Order by Wednesday 5:00pm ET for delivery Thursday
Not in local stock *
Check another branch
Product Spec Sheet
Nylon Insulated Ring Terminal, Length 1.12 Inches, Width .53 Inches, Maximum Insulation .210, Bolt Hole 1/4 Inch, Wire Range #12-#10 AWG, Color Yellow, Copper, Tin Plated

Technical Information

Conductor Size
12-10 AWG
Flamability Class
Rated V-2 Per UL94
Insulation Material
Nylon
Insulation Type
Insulated Nylon
Material
Copper
Standard
UL E9809
Stud Size
1/4 in
Temperature Rating
105 degrees C
Terminal Type
RC
Type
Long Sleeve
Voltage
600 Volt
Wire Size
12 - 10 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210804422
Color
Yellow
Finish
Tin Plated
GTiN
05414363159087
Product UPC
78621080442
Used With
Round Conductors

Dimensions

Height
3 Inch
Thickness
.04 in
Width
1.3 in
Certifications
  • CSA
  • UL
Features
  • Self-insulated with high dieletric-strength nylon sleeves. An inner bronze insulation grip sleeve lengthens the flexing radius of the conductor and eliminates conductor creep.
Compare
