Product image for NSI SC-750 750 MCM Copper Short Bar
Email

NSI SC-750 750 MCM Copper Short Bar

Manufacturer: NSi | Catalog # SC-750 | Cooper Electric Part # 1018834
$4,706.20/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
StandardBarrel TinnedCopperSplice750MCM Standard Barrel Tinned CopperSplices is a type of copper compression connector that is produced from high conductivity copper tubing. They are tin-plated to provide corrosion resistance and are marked with die index and color coded for easy reference. Listed for 35KV maximum when properly installed.

Technical Information

Applications
Terminate, Splice, Tap Power Connectors
Conductor Size
750 kcmil
Material
Copper
Max Temperature
194 degrees F
Number of Conductors
2
Number of Poles
1 Pole
Size
L=3.20 - OD=1.31 - ID=1.03
Standard
UL486
Temperature Rating
90 degrees C
Type
Short Barrel - CU Splice
Voltage
600 Volt

Manufacturer Information

Brand
NSI Industries
Sub Brand
Copper Compression

General Product Info

12-Digit UPC
662381037169
Color
Black
Environmental Conditions
90 degrees C
Finish
Tin Plated
GTiN
00662381037169
Product UPC
66238103716

Dimensions

Height
1.31 Inch
Length
3.2 Inch
Warranty Length
1 yr
Width
1.31 in

Certifications and Compliance

Country of Origin
India
Certifications and Standards
  • cULus
  • UL Listed
  • UL 486A
Features
  • Produced from high conductivity copper tubing
  • Serrations indicate proper crimp locations
  • Tin-plated to provide corrosion resistance
  • Marked with die index and color coded
  • Suitable for use at voltages up to 35kV provided connector is properly installed to cable manufacturer voltage stress relief instructions, 5KV is the maximum voltage in all bare splices
Additional Notes
  • Max ampacity is based on NEC 310.15, insulation type, and conductor material. Please consult your current NEC manual; EXPANDED WIRE RANGE when installed with NSI N12ID dieless compression tool. UL Listed with other tools: FOR TOOL/DIE CRIMPING INFORMATION, PLEASE SEE TABLE ON PAGE 87
