Product image for SQD NLJF36600U31XTW PowerPact multi
Image thumbnail 0
Image thumbnail 1
Email

SQD NLJF36600U31XTW PowerPact multi

Manufacturer: Square-D / Schneider | Catalog # NLJF36600U31XTW | Cooper Electric Part # 1017478
$8,896.96/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page
PowerPact multistandard - L-Frame - 600 A - 100 KA - Micrologic 3.0 trip unit

Technical Information

Actuator
TOGGLE
Amperage
600 Amp
Applications
Distribution
Control Type
Toggle NULL
Interrupt Rating
25, 65, 100 kAIC
Line Rated Current
40 degrees C
Load Rating
ICS 100 KA 220/240 V - AC IEC 947-2-ICS 65 KA 380/415 V - AC IEC 947-2-ICS 65 KA 440/480 V - AC IEC 947-2-ICS 25 KA 500/525 V - AC IEC 947-2
Mounting Type
Unit Mount,Unit Mount
Net Weight
6.2 kg
Number of Poles
3 Pole
Operating Temperature
40 Adegrees C
Range
PowerPact NULL
Standard
CSA C22.2 No 5,CSA C22.2 No 5,IEC 60947-2,IEC 60947-2,NEMA AB1,NEMA AB1,NMX J-266,NMX J-266,UL 489,UL 489,W-C-375B/GEN,W-C-375B/GEN
Storage Temperature
-50-85 degrees C,-50-85 degrees C
TC Connection
TERMINAL NUT LINE SIDE-TERMINAL NUT LOAD SIDE
Trip Range
600-600 A
Trip Type
LI,ELECTRONIC
Type
Circuit breaker
Voltage
525 Volt

Manufacturer Information

Brand
Square D
Sub Brand
L-Frame

General Product Info

12-Digit UPC
785901846505
GTiN
00785901846505
Product UPC
78590184650
Weight
13.67 lb

Dimensions

Depth
110 mm
Height
340 mm
Length
4.33 Inch
Warranty Length
18 mth
Width
140 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CCC,CCC,CE,CE
Country of Origin
USA
